Product Overview
IN STOCK READY TO SHIP.
Contact us and find out why you should buy your next guitar from Liberty Music! We fully inspect your instrument more than once, when received and when shipped. We also will SETUP your instrument at no additional charge prior to shipping your order.
We buy, sell and trade with financing options with Klarna, Affirm and Synchrony available.
We will also beat any competitor's price.
Photos are of the actual pedal for sale that you will receive when purchasing this listing.
CONDITION: AS SEEN PER PHOTO, THE PEDAL, The pedal is in good working condition
SPECS:
Recording media: SD card (512MB to 2GB), SDHC card (4GB to 32GB)
File system: TASCAM original (MTR partition) / FAT32 (FAT partition)
INPUT: A/B
XLR Connectors: XLR-3-31(1GND, 2HOT, 3COLD), BALANCED
Input impedance: 2.4kΩ
Nominal input level: –8dBu
Maximum input level: +8dBu
1/4" TS-jack Connectors: 1/4" (6.3mm) TS-jack, UNBALANCED
Input impedance: 10kΩ or more (INPUT A: MIC/LINE), 1MΩ (INPUT A: GUITAR)
Nominal input level: –10dBV
Maximum input level: +6dBV
Headroom: 16dB
Built-in microphones: Omni-directional condenser microphone × 2
LINE OUT
Connectors: RCA pin-jack
Nominal output level: –10dBV
Maximum output level: +6dBV
PHONES
Connectors: 1/8" (3.5mm) stereo mini jack
Maximum output level: 20mW + 20mW or more (THD+N less than 0.1%, 32Ω loaded)
USB
Connectors: USB Mini-B type
Format: USB2.0 HIGH SPEED mass storage class
Continuous battery operation time: *All times are approximate.
Alkaline battery (EVOLTA): 5.5 hours (using line input/recording)
6 hours (using headphone/playback)
Nickel-metal battery (eneloop) 6.5 hours (using line input/recording)
7 hours (using headphone/playback)
Power: Four AA batteries (Alkaline or nickel-metal battery)
AC adapter (TASCAM PS-P520, sold separately)
Power consumption: 2.4W (Maximum)
Dimensions (W×H×D): 8.7" × 1.74" × 4.99" / 221 × 44.3 × 126.5 mm
Weight: 1.35 lbs. / 610 g (excluding batteries)
Operating temperature: 41F to 95F / 5C to 35C
Backup memory In the PREFERENCES, contents of "Repeat Int", "Auto Power Save", "Contrast", "Back Light" and "FootSW Polarity". Contents of INPUT SETTING (without EQ)
Accessories: 4GB SD card, AA battery × 4, USB cable (31.5" / 80cm), Warranty card, Owner's manual
Audio performance
Frequency response: 20Hz to 20kHz (+1/–3dB, INPUT (MIC/LINE) to LINE OUT)
Distortion: Less than 0.05% (INPUT (LINE) to LINE OUT)
S/N ratio: More than 81dB (INPUT (MIC/LINE) to LINE OUT)
